Liquid Filtration and Solid-Liquid Filter Bag

The customized liquid filtration and solid-liquid filter bags production by Qingdao Star Machine Technology Co.,Ltd.. They are all treated with special singeing, which effectively prevents fiber detachment and contamination of the filtrate, and avoids traditional rolling treatment causing excessive clogging of the filter holes and shortening the service life of the liquid filtration and solid-liquid filter bags. All raw materials are natural white and have not undergone any special bleaching and dyeing treatment, fully meeting environmental standards. Moreover, due to the three-dimensional filtering layer of the needle felt, particles will stay on the inner wall surface and deep layer of the liquid filtration and solid-liquid filter bags due to the deep filtration mechanism when flowing through the filter bag, which has high capture efficiency for solid or colloidal particles. The uniform thickness, stable opening rate, and sufficient strength of the needle felt ensure stable filter bag efficiency and longer service life. If necessary, we can provide free samples.

Product Feature And Application

1.Ultrafine fiber high-efficiency Liquid filtration and solid liquid Filter Bag, also known as AGFLiquid filtration and solid liquid Filter Bag, is manufactured to meet the increasingly strict requirements of the filtration industry by using pure fully welded sealing and filtration technology, pushing industrial technology to another level and leading bag filtration to a new level. The filter material of the ultra-fine fiber high-efficiency liquid filtration and solid-liquid filter bag is pure polypropylene material, which has good lipophilic and hydrophobic properties, and no other chemical components are generated during the filtration process. The structural design of the filter bag is divided into an inner layer coarse filter surface and an outer layer fine filter surface. The inner layer coarse filter surface ensures sufficient dirt holding capacity, reduces filtering resistance, and the outer layer fine filter surface intercepts small particles to ensure filtering accuracy. The design of the cascade structure ensures that impurities are intercepted layer by layer. At the same time, the combination of ultrasonic welding technology ensures extremely high sealing performance, and there will be no bypass side leakage during operation

2.Corrosion resistant Liquid filtration and solid liquid Filter Bag PP filter bag, also known as polypropylene filter bag, is composed of pure polypropylene fiber filter cloth and belongs to a type of liquid filter bag. Polypropylene is a non-toxic, odorless, and tasteless milky white high crystalline polymer with a density of 0 90- "0.91g/cm3. It is particularly stable for water, with a water absorption rate of only 0 01%, with a molecular weight of approximately 80000 to 150000. The liquid filtration and solid-liquid filter bag has good form-ability, good aging resistance, chemical properties, almost no water absorption, and does not react with the vast majority of chemicals. The use of acupuncture to create loose fibrous tissue and increase impurity loading space belongs to the compound interception mode. Its internal honeycomb structure effectively removes solid and soft particles, meaning that larger particle impurities are trapped on the surface of the fiber, while fine particles are captured in the deep layer of the filter material. During use, it will not be damaged due to pressure increase, and has high filtration efficiency.

3. High temperature and acid resistant Liquid filtration and solid liquid Filter Bag is PTFE Liquid filtration and solid liquid Filter Bag. The filter bag continuously operates at a temperature of over 250 degrees Celsius, with an instantaneous temperature of 280 degrees Celsius. It is not afraid of acid, alkali, and oxidation, and is almost non combustible and will not age. Meet harsh working conditions and have an extremely long service life.

4.Metal Liquid filtration and solid liquid Filter Bag is a stainless steel Liquid filtration and solid liquid Filter Bag that is woven into a mesh using stainless steel SUS304 or SUS316 material that does not deform according to specified specifications. After heat setting, it becomes a single wire mesh. High strength, without deformation due to changes in pressure. Monofilament weaving creates a smooth surface that is easy to clean and can be reused multiple times.
